oval soundhole
PostPosted: Fri Jan 18, 2013 11:11 pm
Offline
Contributing Member
Contributing Member

Joined: Tue May 18, 2010 6:42 pm
Posts: 589
First name: Brian
Last Name: Itzkin
State: NY/Granada
Country: USA/Spain
Focus: Build
Well I was using my new LMI fret slotting system and it was all going nicely... until I noticed I some how cut a slot right in between the third and fourth fret [headinwall] [headinwall] [headinwall] Frankly I don't really know how this happened (I think the pic didn't go in the slot, but I just locked down the fretboard and slotted without checking) but I've been trying to figure out how and or if I can save this board. It's going to have binding any way, so I'm not concerned about the edge of the fretboard, but how might I "fix" this mistake? I was thinking of doing some sort of inlay, but then thought that it might just look like some position markers that are in the wrong place.

Any ideas or advice is greatly welcome!

Top
 Profile

theguitarwhisperer
PostPosted: Fri Jan 18, 2013 11:22 pm
Offline
Brazilian Rosewood
Brazilian Rosewood

Joined: Fri Apr 02, 2010 10:35 pm
Posts: 2561
Country: USA
Focus: Repair
Status: Professional
That's not a mistake, that's a "microtone"!

Put a few more in.....

_________________
Old growth, shmold growth!
Top
 Profile

Rod True
PostPosted: Fri Jan 18, 2013 11:39 pm
Offline
Contributing Member
Contributing Member
User avatar

Joined: Tue Jan 04, 2005 10:03 am
Posts: 6680
Location: Abbotsford, BC Canada
How thick is the board?

Here's what I'd probably do (to save it that is....and not toss it)

I'd fill each of the slots with a sliver and glue them in. If you have some room to sand (thickness) I'd then thickness the board on the new "bottom" side. I would then flip the board over, cut the slots again starting from the other end, lay it out first to ensure you don't cut to near the previous slots, taper the board and bind the edges so the first slots are not visible. Proceed as originally planned.

_________________
My Facebook Guitar Page

"There's really no wrong way, as long as the results are what's desired." Charles Fox

"We have to constantly remind ourselves what we're doing....No Luthier is putting a man on the moon!" Harry Fleishman

"Generosity is always different in the eye of the person who didn't receive anything, but who wanted some." Waddy Thomson
Top
 Profile

crich
PostPosted: Fri Jan 18, 2013 11:47 pm
Offline
Koa
Koa

Joined: Fri Jan 27, 2006 4:15 pm
Posts: 655
Location: Columbus,Ohio
Rod True wrote:
How thick is the board?

Here's what I'd probably do (to save it that is....and not toss it)

I'd fill each of the slots with a sliver and glue them in. If you have some room to sand (thickness) I'd then thickness the board on the new "bottom" side. I would then flip the board over, cut the slots again starting from the other end, lay it out first to ensure you don't cut to near the previous slots, taper the board and bind the edges so the first slots are not visible. Proceed as originally planned.


That's interesting- using silver. Why silver? I was about to suggest the same but filing with wood. Clinton
Top
 Profile

Rod True
PostPosted: Fri Jan 18, 2013 11:50 pm
Offline
Contributing Member
Contributing Member
User avatar

Joined: Tue Jan 04, 2005 10:03 am
Posts: 6680
Location: Abbotsford, BC Canada
crich wrote:
Rod True wrote:
How thick is the board?

Here's what I'd probably do (to save it that is....and not toss it)

I'd fill each of the slots with a sliver and glue them in. If you have some room to sand (thickness) I'd then thickness the board on the new "bottom" side. I would then flip the board over, cut the slots again starting from the other end, lay it out first to ensure you don't cut to near the previous slots, taper the board and bind the edges so the first slots are not visible. Proceed as originally planned.


That's interesting- using silver. Why silver? I was about to suggest the same but filing with wood. Clinton


You might want to read it again.......And no, I didn't edit (you can tell from your own post, which of course I can't edit)

;)

_________________
My Facebook Guitar Page

"There's really no wrong way, as long as the results are what's desired." Charles Fox

"We have to constantly remind ourselves what we're doing....No Luthier is putting a man on the moon!" Harry Fleishman

"Generosity is always different in the eye of the person who didn't receive anything, but who wanted some." Waddy Thomson
Top
 Profile

DennisK
PostPosted: Sat Jan 19, 2013 12:20 am
Offline
Contributing Member
Contributing Member
User avatar

Joined: Fri Jan 22, 2010 9:59 pm
Posts: 3626
First name: Dennis
Last Name: Kincheloe
City: Kansas City
State: MO
Country: USA
Focus: Build
Status: Amateur
theguitarwhisperer wrote:
That's not a mistake, that's a "microtone"!

Put a few more in.....

That's what I was thinking as well :)

What scale length is it? Long enough for a terz guitar if you cut it off at the 4th fret? If not, you could cut it at whatever fret leaves an ukulele scale.

Or, route out the portion between the 3rd and 4th frets down to the depth of the fret slots, take some of the offcut from the end of the board and glue in the space, level it, and re-cut the 3rd and 4th slots. The grain discontinuity may be noticeable if someone looks closely, but maybe you could flip the offcut piece around to get the dark line more closely aligned to where it should be. And maybe add some inlays to draw the eye away from the grain of the fingerboard itself :)
Top
 Profile

motojerbear
PostPosted: Sat Jan 19, 2013 12:29 am
Offline
Walnut
Walnut

Joined: Fri Jan 04, 2013 11:42 pm
Posts: 15
First name: Jeremy
Last Name: Chambers
Focus: Build
Status: Amateur
That is so crazy cause I read silver too!!! idunno
Top
 Profile

dpm99
PostPosted: Sat Jan 19, 2013 1:01 am
Offline
Cocobolo
Cocobolo
User avatar

Joined: Thu Oct 09, 2008 11:27 pm
Posts: 313
Location: McKinney, TX
First name: David
Last Name: Morris
City: McKinney
State: TX
Focus: Build
Status: Amateur
Well, he's binding the fretboard. Silver would technically work. ;)

_________________
David Morris
Top
 Profile

runamuck
PostPosted: Sat Jan 19, 2013 1:16 am
Offline
Cocobolo
Cocobolo

Joined: Sun Jun 21, 2009 1:08 pm
Posts: 426
First name: jim
Last Name: mccarthy
City: ojai
State: ca
Zip/Postal Code: 93023
Country: usa
Focus: Build
If it were me, I'd replace it. To accept an error like that emotionally
colors the rest of the building process in a less than positive way.
Top
 Profile

Clay S.
PostPosted: Sat Jan 19, 2013 8:37 am
Offline
Brazilian Rosewood
Brazilian Rosewood

Joined: Sun Mar 30, 2008 8:20 am
Posts: 5968
To use the board at that scale length I would follow Rod's suggestion, except I would reslot the other side starting at the same end, only 1/2 the distance down from the smallest fret interval. That should keep all the fret slots from lining up with any of the original slots.
Dennis also has a good idea for using the board for a short scale instrument, especially since there is plenty of length on the lower end to cut more fret slots to keep a 20 fret board.
Top
 Profile

Tom West
PostPosted: Sat Jan 19, 2013 8:46 am
Offline
Contributing Member
Contributing Member

Joined: Sun Jan 27, 2008 4:10 pm
Posts: 2764
First name: Tom
Last Name: West
State: Nova Scotia
Country: Canada
Focus: Build
Status: Amateur
Possible uke...........??
Tom

_________________
A person who has never made a mistake has never made anything!!!
Top
 Profile

dzsmith
PostPosted: Sat Jan 19, 2013 9:38 am
Offline
Contributing Member
Contributing Member
User avatar

Joined: Fri May 18, 2012 8:35 pm
Posts: 2660
First name: D
Last Name: S
State: TX
Country: USA
Focus: Build
Status: Amateur
runamuck wrote:
If it were me, I'd replace it. To accept an error like that emotionally
colors the rest of the building process in a less than positive way.

I agree- shoot for perfection when you have a chance to redo something.

_________________
wah
Wah-wah-wah-wah
Wah
Top
 Profile

cphanna
PostPosted: Sat Jan 19, 2013 9:39 am
Offline
Koa
Koa

Joined: Sat Apr 19, 2008 10:08 pm
Posts: 1958
Location: Missouri
First name: Patrick
Last Name: Hanna
State: Missouri
Country: USA
Brian, I'm sorry this happened to you, but I'm really glad you posted your question. There are some great suggestions here. I'm glad I read your thread. Please do follow up and let us all know which strategy you use and how it works for you.
Patrick
Top
 Profile

runamuck
PostPosted: Sat Jan 19, 2013 1:00 pm
Offline
Cocobolo
Cocobolo

Joined: Sun Jun 21, 2009 1:08 pm
Posts: 426
First name: jim
Last Name: mccarthy
City: ojai
State: ca
Zip/Postal Code: 93023
Country: usa
Focus: Build
If I were to repair it I think Todd's suggestion is best.
But how will you match up the grain?
Top
 Profile

Mike_P
PostPosted: Sat Jan 19, 2013 1:32 pm
Offline
Koa
Koa

Joined: Tue Jan 22, 2008 8:57 pm
Posts: 780
Location: Austin, Texas
and just what is the cost of that piece of wood?

if flipping it over is not an option just throw it away and start over...I've found that most attempts at repairing a screw up of this caliber are usually a joke and can many times be rooted in being too "greedy"...take the loss and chalk it up to learning something new the hard way...
Top
 Profile

Alain Moisan
PostPosted: Sat Jan 19, 2013 1:52 pm
Offline
Contributing Member
Contributing Member
User avatar

Joined: Fri Feb 01, 2008 8:47 am
Posts: 1244
Location: Montreal, Canada
Focus: Build
Status: Amateur
Hi Brian,

I just want to say that I encourage you to go for the fix. At least try it. Your case is the perfect example of the "mistakes are opportunity" saying. Regardless of how cheap an indian rosewood fretboard is, wood is precious.

Personnaly, I would go with Rod's suggestion, although pay attention to Clay's suggestion of reslotting 1/2 the shortest distance between slots.

Keep us informed!

_________________
Alain Moisan
Former full time builder of Acoustics, Classicals and Flamencos.
(Now building just for fun!)


Last edited by Alain Moisan on Sat Jan 19, 2013 2:47 pm, edited 2 times in total.

Top
 Profile

Ron Belanger
PostPosted: Sat Jan 19, 2013 2:00 pm
Offline
Contributing Member
Contributing Member

Joined: Thu Dec 14, 2006 6:44 am
Posts: 319
Location: Canada
First name: Ron
Last Name: Belanger
Focus: Build
Status: Semi-pro
I think the opportunity to repair this ala Todd's suggestion is of greater benefit than throwing it away and starting over. It's easy to start over, but to make a repair that is invisible or near invisible is a skill really worth learning and a great one to have in your bag of tricks.
Top
 Profile

bluescreek
PostPosted: Sat Jan 19, 2013 5:00 pm
Offline
Brazilian Rosewood
Brazilian Rosewood

Joined: Mon Jan 28, 2008 5:21 am
Posts: 4918
Location: Central PA
First name: john
Last Name: hall
City: Hegins
State: pa
Zip/Postal Code: 17938
Country: usa
Focus: Build
Status: Professional
Simple fix
You have enough fall off at the end of the board . You can inlay that between the frets and recut. I have do that when I do conversions. To fill the slot will show to take out the entire field between the frets it will hide better.

_________________
John Hall
blues creek guitars
Authorized CF Martin Repair
Co President of ASIA
You Don't know what you don't know until you know it
Top
 Profile

WudWerkr
PostPosted: Sat Jan 19, 2013 5:16 pm
Offline
Contributing Member
Contributing Member
User avatar

Joined: Mon Jul 27, 2009 7:52 am
Posts: 4524
First name: Big
Last Name: Jim
State: Deep in the heart of Bluegrass
Country: usa
Focus: Build
Status: Amateur
motojerbear wrote:
That is so crazy cause I read silver too!!! idunno



+ 1 laughing6-hehe

_________________
The Shallower the depth of the stream , The Louder the Babble !
The Taking Of Offense Is the Life Course Of The Stupid One !
Wanna Leave a Better Planet for our Kids? How about Working on BETTER KIDS for our Planet !
Forgiveness is the ability to accept an apology that you will probably NEVER GET
The truth will set you free , But FIRST, it will probably Piss you Off !
Creativity is allowing yourself to make Mistakes, Art is knowing which ones to Keep !
The Saddest thing anyone can do , is push a Loyal Person to the point that they Dont Care Anymore
Never met a STRONG person who had an EASY past !
http://wiksnwudwerks.blogspot.com/
http://www.facebook.com/groups/GatewayA ... rAssembly/
Top
 Profile

sprouseod
PostPosted: Sun Jan 20, 2013 2:26 am
Offline
Contributing Member
Contributing Member

Joined: Fri Mar 28, 2008 8:35 am
Posts: 348
Location: Spartanburg SC
First name: Richard
Last Name: Sprouse
City: Spartanburg
State: SC
Zip/Postal Code: 29302
Country: USA
Focus: Build
Status: Amateur
Depends on who the guitar is for. If it's just for you, you could just inlay a piece of mother of pearl across that slot then do the same thing on 5 7 9 etc. It may have a cool effect. Or just come up with some design that incorporates at straight line just for that slot. If it is for someone else start over.

Just a thought
Top
 Profile

nyazzip
PostPosted: Sun Jan 20, 2013 3:13 am
Offline
Contributing Member
Contributing Member

Joined: Mon Jul 11, 2011 12:43 am
Posts: 1326
Location: chicagoland, illinois
City: chicagoland
State: illinois
Country: usa
Focus: Build
Status: Amateur
this is off-subject but that workbench surface in the background looks like art to me....!
Top
 Profile

Tom West
PostPosted: Sun Jan 20, 2013 9:10 am
Offline
Contributing Member
Contributing Member

Joined: Sun Jan 27, 2008 4:10 pm
Posts: 2764
First name: Tom
Last Name: West
State: Nova Scotia
Country: Canada
Focus: Build
Status: Amateur
It may be a Pollock cast off...........!!
Tom

_________________
A person who has never made a mistake has never made anything!!!
Top
 Profile

weslewis
PostPosted: Sun Jan 20, 2013 9:19 am
Offline
Contributing Member
Contributing Member

Joined: Sun Jan 10, 2010 11:40 am
Posts: 764
First name: wes
Last Name: Lewis
City: Garland
State: Tx.
Zip/Postal Code: 75044
Focus: Build
sliver whittling wood!!!!!!! idunno beehive :o

_________________
MK5acoustics.com
Top
 Profile

Clinchriver
PostPosted: Sun Jan 20, 2013 10:36 am
Offline
Contributing Member
Contributing Member

Joined: Sat Feb 19, 2011 7:44 pm
Posts: 1225
Location: Andersonville
State: Tennessee
Country: USA
Focus: Build
Status: Professional
Do a wedge shaped inlay with some darker wood.......... do several, make it look like that was your intention in the first place.
Top
 Profile

bluesman_d
PostPosted: Sun Jan 20, 2013 11:05 am
Offline
Walnut
Walnut

Joined: Sat Jan 19, 2013 8:42 pm
Posts: 5
First name: Darren
Last Name: Galloway
City: Benton
State: IL
Zip/Postal Code: 62812
Country: usa
Focus: Repair
Status: Semi-pro
Todd Stock wrote:
DennisK wrote:

Or, route out the portion between the 3rd and 4th frets down to the depth of the fret slots, take some of the offcut from the end of the board and glue in the space, level it, and re-cut the 3rd and 4th slots. The grain discontinuity may be noticeable if someone looks closely, but maybe you could flip the offcut piece around to get the dark line more closely aligned to where it should be. And maybe add some inlays to draw the eye away from the grain of the fingerboard itself :)


What Dennis said...pretty much old hat for repair guys dealing with truss rod anchors, inlay replacement, etc. You can likely shift the filler piece laterally and piece it in on the other side for a perfect match...looking at the board, I don't see any reason why anyone would be able to see the mistake once repaired. FWIW, don't bother recutting the 3 and 4 fret slots - just stick a piece of .020 UHMW-PE in when gluing up...widen with a fret saw if necessary. Finally - epoxy filled with rosewood dust would disguise this joint...under finish, the joint should be invisible.

Had to get a bass fretboard out on a repair...had no stock long enough...just overlapped two pieces of rosewood joggled between a couple frets...could not be detected and plenty strong and stiff if done over several frets. Much less signature than a scarf.


This is the best solution. [:Y:]

Or you can always chuck it up to a learning lesson and hang it on the wall to remind you to always check your work. I have a few of those hanging around. :lol:

_________________
I wanted something very dense, something that would sustain long and more pieces of wood that would be soft, sweet, for more of a mellow sound.

~ Les Paul
Top
 Profile

Display posts from previous:  Sort by
Post new topic Reply to topic  Page 1 of 2
  [ 29 posts ]  Go to page 1, 2  Next

Board index » Luthiers Forum Rooms » Guitar Building Forum

All times are UTC - 5 hours


Who is online

Users browsing this forum: rbuddy and 14 guests

You cannot post new topics in this forum
You cannot reply to topics in this forum
You cannot edit your posts in this forum
You cannot delete your posts in this forum
You cannot post attachments in this forum

Jump to:
Powered by phpBB® Forum Software © phpBB Group
phpBB customization services by 2by2host.com
